Industrial universal BE-20CT 20/5A ac low voltage split core current transformer

Industrial universal BE-20CT 20/5A ac low voltage split core current transformer

1.1Product Description

1,The Current Transformers are made according to IEC 44-1,BS398,DIN42600 standards
2,All case are made of non-combustible plastic material according to UL-94V0.
3,Insulation class:E(120 °C max)
4,Ambient temperature: -20°C~ +45°C( +65°C)
5,Storage temperature: -50°C~ +80°C
6,Test voltage:4KV 50Hz 1min
7, Operating frequency:50hz-60hz
8,Rated secondary current:5 or 1 A
9,Rated burden:1, 1.5, 2.5, 3.75, 5, 7.5, 10, 12.5, 15, 20, 30, 45, 60VA





1.2Product Application



1.3 Product Packaging

          Both products for overseas and domestic sales have the same high quality and are same carefully packaged. Perfection is our best interpretation to professionalism.


       Anti-moisture, anti-extrusion, anti-shock and anti-exposure.
       Specially thickened quality packaging cartons, anti-moisture and anti-shock.

       Professional bubble bags inside to prevent vibration during transportation.

Our meters are carefully packed layer by layer to ensure they can withstand long-distance transit to arrive at customers

1.4 Professional Storage

  Neat warehouse and clean production line

1.5 Our Customer
